| Pitch(mm) | 5mm | 6mm | 8mm | 10mm |
| Module Size(mm) | 160*80 | 192*96 | 160*80 | 160*80 |
| Module Resolution(mm) | 32*16 | 32*16 | 40*20 | 16*8 |
| LED Lamp | SMD1921 | SMD3535 | SMD3535 | SMD3535 |
| Screen Resolution | 4000dots/m² | 24414dots/m² | 15625dots/m² | 10000dots/m² |
| Brightness | >5500cd/m² | >6500/m² | >6500/m² | >6500/m² |
| Ave.Power Consumption | 190W/m² | 200W/m² | 200W/m² | 180W/m² |
| Max.Power Consumption | 480W/m² | 500W/m² | 530W/m² | 450/m² |
| Cabinet size(mm) | W1280*H960*T100mm (Standard) | |||
| W1280*H640*T100mm | ||||
| W640*H960*T100mm | ||||
| W640*H640*T100mm | ||||
| Cabinet Material | Aluminum Profile | |||
| Cabinet Weight | ≤32kg | |||
| IP Level | IP67 | |||
| Gray Level | 14bit | |||
| Viewing Angle | V:140°/ H:140° | |||
| Refresh Rate | 1920-3840 | |||
| Maintenance Mode | Front and Full Maintenance | |||
| Working Temperature | -20°C~50°C,10%~90% RH | |||
| Input Signal | VGA, DVI, HDMI, SDI | |||
